Craftsman DGS 6500 Specifications
The Craftsman DGS 6500 is a 2WD garden tractor from DGS Series. This model was manufactured by AYP from 2007 to 2008. The Craftsman DGS6500 tractor is powered by 44 cu.in (725 cc) Kohler Courage SV735 4-cycle V-twin cylinder OHV air-cooled gasoline engine with a rated power of 26 hp (19.4 kW). The tractor is fitted with several types of transmission: Peerless gear transmission with 6 forward and 1 reverse gears, Tuff Torq K66Y hydrostatic transmission with infinite forward and reverse gears, or Hydro Gear hydrostatic transmission with infinite forward and reverse gears.
The Craftsman DGS 6500 tractor is equipped with a manual steering system, electric PTO clutch, mechanical disc brakes, 16x6.50-6 front tires, and 23x10.50-8 rear tires. The tractor is compatible with 48" or 54" mid-mount mower deck with cutting height of 1.5-4.0" (37-100 mm) and mechanical lift system.
| Engine Specs |
Engine Model ..................... Kohler Courage SV735
Engine Type ..................... 4-cycle V-twin cylinder OHV air-cooled gasoline engine
Number of Cylinders ..................... 2
Piston Displacement, cu.in (cc) ..................... 44.0 (725)
Cylinder Bore, in (mm) ..................... 3.27 (83.0)
Piston Stroke, in (mm) ..................... 2.64 (67.0)
Engine Power, Hp (kW) ..................... 26.0 (19.4)
Maximum Torque, Nm (ft-lb) ..................... 56.2 (41.5)
Fast Idle Speed, rpm ..................... 2800
Low Idle Speed, rpm ..................... 1500
Compression Ratio ..................... 9:1
Fuel System Type ..................... Carburetor
Carburetor Type ..................... One-Barrel, fixed main jet
Fuel Pump Type ..................... Pulse type
Fuel Filter Type ..................... In-line
Governor Type ..................... Centrifugal mechanical flyweight
Cooling System ..................... Air Intake
Air Cleaner Type ..................... Replaceable, paper element
Lubrication System ..................... Full-Pressure
Oil Filter Type ..................... Full-flow
Ignition System ..................... Electronic
Spark Plug ..................... Champion RC12YC
Spark Plug Gap, in (mm) ..................... 0.03 (0.76)
Fuel Tank Capacity, gal (L) ..................... 4.0 (15.2)
Oil Capacity, qts (L) ..................... 1.9 (1.8)
| Electrical System |
Electrical System Rating, Volts ..................... 12
Charging System ..................... Alternator
Alternator Rating, Amps ..................... 15
Starter Type ..................... Electric
Number of Batteries ..................... 1
Battery Voltage, Volts ..................... 12
Battery, AH ..................... 28
Battery, CCA ..................... 230
Electric Ground ..................... Negative
| Power Take Off |
PTO Operational Type ..................... Independent
PTO Clutch ..................... Electric
PTO Speed, rpm ..................... 2800
| Standard Transmission |
Transmission Model ..................... Peerless P820-040
Transmission Type ..................... Gear
Gearbox Type ..................... 6F/1R
Number of Forward Gears ..................... 6
Number of Reverse Gears ..................... 1
Maximum Forward Speed, mph (kph) ..................... 4.3 (7.0)
Maximum Reverse Speed, mph (kph) ..................... 1.3 (2.1)
| Optional Transmission |
Transmission Model ..................... Tuff Torq K66Y
Transmission Type ..................... Hydrostatic
Number of Forward Gears ..................... Infinite
Number of Reverse Gears ..................... Infinite
Oil Capacity, qts (L) ..................... 2.75 (2.60)
Maximum Forward Speed, mph (kph) ..................... 5.8 (9.3)
Maximum Reverse Speed, mph (kph) ..................... 2.1 (3.4)
| Optional Transmission |
Transmission Model ..................... Hydro Gear
Transmission Type ..................... Hydrostatic
Number of Forward Gears ..................... Infinite
Number of Reverse Gears ..................... Infinite
Maximum Forward Speed, mph (kph) ..................... 5.5 (8.8)
Maximum Reverse Speed, mph (kph) ..................... 2.4 (3.9)
| Wheels and Tires |
Wheel Drive System ..................... 2WD 4x2
Steering Configuration ..................... Front steer
Steering System ..................... Manual sector and pinion
Brakes Type ..................... Mechanical disc
Front Tire Size ..................... 16x6.50-6
Rear Tire Size ..................... 23x10.50-8
| 48" Mower Deck |
Mower Deck Type ..................... Mid-mount
Number of Blades ..................... 3
Cutting Width, in (mm) ..................... 48 (1215)
Cutting Height, in (mm) ..................... 1.5-4.0 (37-100)
Cut Positions ..................... 7
Drive System ..................... Belt
Lift System ..................... Mechanical
| 54" Mower Deck |
Mower Deck Type ..................... Mid-mount
Number of Blades ..................... 3
Cutting Width, in (mm) ..................... 54 (1370)
Cutting Height, in (mm) ..................... 1.5-4.0 (37-100)
Cut Positions ..................... 7
Drive System ..................... Belt
Lift System ..................... Mechanical
